Midas M32R LIVE 40-channel Digital Mixer
40-channel Digital Mixing Console with 16 Midas Preamps, 25 Mix Buses, Over 50 Built-in FX, 5″ Full-color Display, and Klark Teknik DN32-LIVE Expansion Module
Midas M32R LIVE Digital Mixing Console Features:
Rich, vibrant sound from 16 Midas preamps
Incredibly strong yet lightweight, thanks to carbon fiber, aluminum, and steel construction
Outstanding signal path with 48kHz digital conversion
Impeccable sound quality throughout your signal path, with time-aligned and phase-coherent mix buses
Best-in-class motorized faders rated at over 1 million life cycles
32 channels of live recording and playback via a pre-installed Klark Teknik DN32-LIVE expansion module
Tech Specs
- Type:Digital Mixer
- Channels:40
- Inputs – Mic Preamps:16 x XLR
- Phantom Power:48V, Switchable per Input
- Inputs – Line:1 x Dual RCA Stereo (aux)
- Inputs – Other:6 x 1/4″ TRS (aux)
- Outputs – Main:8 x XLR (main), 2 x 1/4″ TRS (monitor)
- Outputs – Other:6 x 1/4″ TRS (aux), 1 x Dual RCA Stereo (aux)
- Busses/Groups:25 time-aligned/phase-coherent mix buses, 8 DCA groups
- Talkback:1 x XLR
- MIDI I/O:In/Out/USB
- Data I/O:1 x EtherCon (Ultranet), 2 x EtherCon (AES50), 1 x Ethernet
- Headphones:2 x 1/4″ TRS (stereo)
- USB:1 x Type B, 1 x Type A
- Computer Connectivity:USB, Ethernet
- Faders:16 x Input Faders, 1 x Main Fader
- A/D Resolution:24-bit/48kHz
- EQ Bands:4-band EQ
- Effects:8 x Stereo FX Engines
- Signal Processing:Gate, Compressor
- Features:100-band RTA, 100 scenes, 100 Snippets, 32-bit/48kHz SD Card recording
- DAW Control:Yes
- Screen:5″ TFT Display
- Storage:2 x SD card slots
- Power Source:Standard IEC AC cable
- Height:8.2″
- Depth:24.3″
- Width:18.8″
- Weight:31.5 lbs.
