Behringer CX3400 V2

Brand: Behringer


Behringer Super-X Pro CX3400 V2
Stereo 2- and 3-way, Mono 4-way Crossover with Limiters, Adjustable Time Delays, and CD Horn Correction

Behringer Super-X Pro CX3400 V2 Crossover Features:

  • Stereo 2- and 3-way, mono 4-way crossover
  • CD horn correction supplies constant-directivity compensation
  • Internal switch-mode power supply for worldwide, 100-volt to 240-volt operation
  • State-of-the-art Linkwitz-Riley filters with 24dB/octave
  • Low-frequency output summing function provides mono output for your subwoofer
  • Absolutely flat summed amplitude response, zero phase difference
  • Individual output Gain controls for all bands
  • Individual output Mute switches for easy band adjustment
  • Individual phase reverse switches for solving polarity issues
  • Individual limiters on each output offer superior loudspeaker protection
  • Time delay for phase-aligning your drivers
  • Switchable 25Hz low cut filter on each input for low-frequency driver protection
  • Servo-balanced and gold-plated XLR connectors for all inputs and outputs
  • Ultra-high-precision potentiometers for ultimate accuracy and repeatability
  • Illuminated switches for secure operation in dark stage environments
  • High-quality components and exceptionally rugged construction ensure long life

Tech Specs

  • Number of Channels:Stereo
  • Modes:2-way, 3-way, 4-way (mono)
  • Filter Types:Linkwitz-Riley
  • Filters:24 dB/Octave
  • Crossover Frequencies – Stereo:Variable ; 44Hz-930Hz, 440Hz-9.3kHz
  • Crossover Frequencies – Mono:Variable
  • Inputs:2 x XLR
  • Outputs:3 x XLR (ch 1), 3 x XLR (ch 2)
  • Rack Spaces:1U
  • Height:1.7″
  • Depth:5.8″
  • Width:19″
  • Weight:3.7 lbs.
  • Manufacturer Part Number:cx3400v2
